Solid State Logic Origin Analogue In-Line Console

BRAND: Solid-State-Logic
|
MODEL: Origin
OUT OF STOCK | CONDITION: New
WARRANTY: Official Manufacturer Warranty
COLOR
black Solid State Logic Origin Analogue In-Line Console color image
Special Deal
Left in Stock!
Deal Claimed ( %)
special offer image
✕
Offer Price Valid For Limited Time
Price: ₹ 377475.00
Today's Price: ₹
Rs.377475 (inclusive of all taxes) Free Delivery
OUT OF STOCK
return logo Easy
Return
delivery icon Fast Delivery
sheild icon Payment Protection
Check For Delivery ✎
original stamp icon
offer icon

More Offers ⨯

  • 2% Discount On transaction using Debit card
  • * Special Offer: 3% Off on All bank UPI
    * Special Offer: 2% Off on All bank Debit Card
    * No cost EMI Available on All Bank Credit Card

Product Description

  • True analog signal path with SSL's classic sound.
  • SuperAnalogue™ technology for enhanced clarity and precision.
  • Channel strips with 4-band EQ and dynamics (compressor/limiter).
  • Multiple analog and digital routing options.
  • 16x2 monitoring system with source selection.
  • SSL Bus Compressor for mix cohesion.
IN THE BOX
Sales Package Solid State Logic Origin Analogue In-Line Console
General
BrandSolid-State-Logic
ModelOrigin
Colorblack
USB I/O

1 x USB-C Female Input/Output
Audio I/O

8x Combo XLR-1/4" Line/Mic Input
4x 1/4" TRS Hi-Z/Instrument Input (Front Panel)
1x DB-25 Line Input
1x DB-25 Line Input (Insert Return)
1x DB-25 Line Output (Insert Send)
Digital I/O

AES/EBU Outputs: 4 x XLR (Male)
ADAT Output and ADAT Link In: 2 x Optical TOSLINK Port
Wordclock Input and Output: 2 x BNC
Impedance

Mic In to Insert Send
Input: 400, 600, 1200, or 12,000 Ohms
Output: 70 Ohms

Line In to Insert Send: <22 Kilohms

Hi-Z to Insert Send: 1 Megohm

Insert Return to ADC: 10 Kilohms
Gain

Mic In to Insert Send: 4.8 to 65.5 dB ± 0.1 dB
Gain Matching: < 0.08 dB

Line In to Insert Send: -0.4 to 30 dB ± 0.1 dB
Gain Matching: <0.08 dB

Hi-Z to Insert Send: 10.9 to 41.3 dB ± 0.1 dB
Gain Matching: <0.08 dB
Noise Floor

Mic In to Insert Send: <-97.3 dBu

Line In to Insert Send: -89.7 dBu Typical

Hi-Z to Insert Send: 11 dB, Unweighted, 20 Hz to 20 kHz, 150R Termination: < 86 dBu Typical
EIN

Mic In to Insert Send: 65 dB, A-weighted, 20 Hz to 20 kHz, 150R Termination: -130 dBu Typical, -129 dBu Nominal
THD+N

Mic In to Insert Send: < -92 dB / 0.0025 % (17 dB, 20 dBu out, 1 kHz)

Line In to Insert Send: 0 dB, Unweighted, 20 Hz to 20 kHz, 150R Termination: -89.6 dB / 0.0033% Typical

Insert Return to ADC:-105 dB / 0.0005% Typical
Frequency Response

Mic In to Insert Send: 20 to 20 kHz, Any Gain (± 0.2 dB)

Insert Return to ADC: ± 0.035 dB, -3 dB Low Roll-Off < 5 Hz
Crosstalk

Mic In to Insert Send
Aggressor 15 dBu 50 Hz In, 5 dB Gain, 20 dBu Out; Adjacent Channels 150R Terminator, 35 dB Gain: < -108 dB
Aggressor 15 dBu 1 kHz In, 5 dB Gain, 20 dBu Out; Adjacent Channels 150R Terminator, 35 dB Gain: < -105 dB
Aggressor 15 dBu 10 kHz In, 5 dB Gain, 20 dBu Out; Adjacent Channels 150R Terminator, 35 dB Gain: < -81 dB

Insert Return to ADC
23.9 dBu In, 20 Hz to 20 kHz, 1 Channel Driven, All Other Channels 150R Terminated: < 105 dB
23.9 dBu In, 1 kHz, 1 Channel Driven, All Other Channels 150R Terminated: < 115 dB
Maximum Input Level

Mic In to Insert Send: >21.5 dBu (At Minimum Gain)

Line In to Insert Send: 26.5 dBu (At Minimum Gain)

Hi-Z to Insert Send: >15.5 dBu (Unbalanced, Minimum Gain)
Power Source

AC Input (Included)
AC Input Power

100 to 240 VAC, 50 / 60 Hz
Dimension
Dimension482.6 x 302.8 x 88.1 mm
Weight5.9 kg
Warranty
Warranty TypeOfficial Manufacturer Warranty
Warranty Period1 year
