IN THE BOX | |
---|---|
Sales Package | Yamaha AG08 Live Streaming Mixer, User documentation |
General | |
---|---|
Brand | Yamaha |
Model | AG08 |
Color | BLACK |
Specifications | |
---|---|
Input Channels | Mono[MIC/LINE]: 2 - CH1: Combo (Mic, +48 V phantom power / Line), 3.5 mm (1/8”) stereo mini (Headset mic, Plug-in power), CH2: Combo (Mic, +48 V phantom power / Guitar input / Line) *CH1 input and Headset mic cannot be used simultaneously Stereo[LINE]: 3 - CH3/4: LR Stereo Phone, CH5/6: LR Stereo RCA/3.5 mm stereo mini (AUX), CH7/8: 4-pole mini in/out (TRRS) AUX: 1 - Stereo mini Smartphone: 1 - 4-pole mini input/output (TRRS) USB: 1 - USB: 4 Stereo Audio Channels (Streaming, Voice, AUX, FROM DAW) |
Output Channels | PHONES: 2 - CH1: 6.3 mm (1/4") Stereo / HEADSET mini PHONES *Cannot be used simultaneously, CH2: PHONES Smartphone: 1 - 4-pole mini input/output (TRRS) MONITOR OUT: 2 - LR Stereo: XLR, 1/4 TRS Phone STEREO OUT: 1 - MIX: LR stereo TRS Phone USB: 1 - USB: 4 Stereo Audio Channels (Streaming, Voice, AUX, TO DAW), 8 Channels Direct Out *In Windows environment, ASIO channel and USB 2.0 exist independently. Please check the block diagram for details. |
Bus | 4 Stereo |
Functions | MUTE button x 5, CH1 FX preset button x 4, Sound pad x 6, +48 V phantom power x 2, GUITAR(HI-Z) x 1, PAD x 2, GAIN HIGH/LOW x 1, LINE/USB x 3, STREAMING ON/OFF x 3, CUE x 1, MIX MINUS (CH1, 2) |
Power requirement | DC 12 V, 1.5 A / USB-C 5 V, 1.5 A |
Power consumption | Max. 7.5 W |
Dimension | |
---|---|
Dimension | 290 x 88 x 222 mm |
Weight | 2.2 Kg |
Warranty | |
---|---|
Warranty Type | Official manufacturer warranty |
Warranty Period | 1 Year |
