| IN THE BOX | |
|---|---|
| Sales Package | Focusrite Scarlett 4i4 USB-C Audio/MIDI Interface (4th Generation) USB-C to USB-C Cable USB-C to USB-A Adapter USB-C Power supply |
| General | |
|---|---|
| Brand | Focusrite |
| Model | Scarlett 4i4 4th gen |
| Color | black |
Channels of I/O | Analog: 4 Inputs / 4 Outputs at 192 kHz |
Maximum Sampling Rate | 192 kHz / 24-Bit |
Number of Microphone Inputs | 2 |
Input Level Adjustment | 2x Knob |
Gain/Trim Range | Mic/Line Inputs: Up to +69 dB Hi-Z Inputs: 62 dB |
Analog Audio I/O | 2x Combo XLR-1/4" TRS Balanced/Unbalanced Mic/Line/Hi-Z Input (Front Panel) 2x 1/4" TRS Balanced/Unbalanced Line Input 4x 1/4" TRS Balanced/Unbalanced Line/Monitor Output 1x 1/4" TRS Headphone Output (Front Panel) |
Phantom Power | 48 V, Selectable On/Off |
Host Connection / USB | 1x USB-C |
Host Connection Protocol | USB 2.0 |
MIDI I/O | 1x DIN 5-Pin Input 1x DIN 5-Pin Output |
Frequency Response | Combo XLR-1/4" Mic Inputs: 20 Hz to 20 kHz ±0.06 dB Combo XLR-1/4" Line Inputs: 20 Hz to 20 kHz ±0.05 dB 1/4" Line Inputs: 20 Hz to 20 kHz ±0.02 dB Combo XLR-1/4" Hi-Z Inputs: 20 Hz to 20 kHz ±0.15 dB |
Maximum Input Level | Combo XLR-1/4" Mic: 16 dBu Combo XLR-1/4" Line: 22 dBu 1/4" Line: 22 dBu Combo XLR-1/4" Hi-Z: 12 dBu |
Maximum Output Level | 1/4" Line: +16 dBu |
Headphone Output Power | 1/4": 57 mW into 33 Ohms 27 mW into 300 Ohms |
Impedance | Combo XLR-1/4" Mic Inputs: 3 Kilohms Combo XLR-1/4" Line Inputs: 60 Kilohms 1/4" Line Inputs: 60 Kilohms 1/4" Line Outputs: 100 Ohms Combo XLR-1/4" Hi-Z Inputs: 1 Megohms 1/4" Headphone Outputs: < 11 Ohm |
Dynamic Range | 1/4" Headphone: 112 dB (at 33 Ohms) 115 dB (at 300 Ohms) Combo XLR-1/4" Hi-Z Inputs: 113 dBA Combo XLR-1/4" Line Inputs: 115.5 dBA 1/4" Line Inputs: 115.5 dBA Combo XLR-1/4" Mic Inputs: 116 dBA 1/4" Line Outputs: 120 dB Digital A/D Converters: 130 dB Digital D/A Converters: 130 dBA |
THD+N | Combo XLR-1/4" Mic Inputs: -100 dB (at 8 dB Gain) Combo XLR-1/4" Line Inputs: -100 dB (at 8 dB Gain) Combo XLR-1/4" Hi-Z Inputs: -80 dB (at Minimum Gain) 1/4" Line Inputs: -105 dB 1/4" Line Outputs: -112 dB 1/4" Headphone Outputs: -99 dB (at 33 Ohms) -108 dB (at 300 Ohms) Digital A/D Converters: -115 dB Digital D/A Converters: -115 dB |
Sample Rates | 44.1 to 192 kHz |
Power Requirements | USB Bus Power, USB Power Adapter (Not Included) |
Power Consumption | 7.5 W |
| Dimension | |
|---|---|
| Dimension | 18.01 x 12.9 x 5.89 cm |
| Weight | 816 g |
| Warranty | |
|---|---|
| Warranty Type | Official Manufacturer Warranty |
| Warranty Period | 1 year |
